The advanced technology we have learned and introduced at home and abroad should enable our Wear Resistant Alumina Ceramics, Ceramic Rubber Lining Wear Plates, Surfacing Wear Resistant Liner to achieve considerable economic benefits. The company's R&D team has a strong sense of innovation and has mastered a variety of mature R&D technologies. From design to research and development, the products strive to create a combination of practicality and artistry to meet the needs of modern commercial consumption. In accordance with the strategic thinking of high starting point, high requirements and heavy integration, the company takes technological innovation as the core and adheres to the four-in-one cooperation concept of "production, learning, research and application". Quality policy is an integral part of the general policy of enterprise operation. Different enterprises can have different quality policies.
It is widely used in engineering machinery, metallurgical machinery, coal industry, mining machinery,environmental protection machinery,the feeder,container,dumper bodies, sieve plate,hoister,edge plate,wheel gear,cutter etc other industry.
Specifications:
Grade: Chrome carbide overlay plate
Place of Origin: Shandong, China
Brand Name: Qishuai
Model Number: QS-thickness
Type: Steel Plate
Technique: Open arc
Surface Treatment: Hardfacing
Application: Wear solution
Special Use: CCO plate
Width: 1450mm, customized
Length: 2840mm, customized
Product Name: Heat resistant steel plate with super wear resistance
Keyword: Heat resistant steel plate
Chemical composition: C: 3.0~5.0 % Cr: 18~30%
Microstructure: Above 50% volume fraction chromium carbide
Hardness: HRC 50-62/HV 660-840
Wear resistance: Super good
Impact resistance: Good
Application:
Heat resistant steel plate with super wear resistance has a good resistance to abrasion.
It is widely used in engineering machinery, metallurgical machinery, coal industry, mining machinery,environmental protection machinery,the feeder,container,dumper bodies, sieve plate,hoister,edge plate,wheel gear,cutter etc other industry.
Description:
The overlay alloy has a high amount of chromium carbide hard particles. These particles are distributed evenly throughout the layer, creating a strong microstructure. The hardness is HRC 58~62 and depends on the overlay's thickness.
The main ingredients of Qishuai plate are C(%): 3.0~5.0 and Cr(%): 18~25. This chemical proportion results in a large amount of Cr7C3 chrome carbide hard particles. The micro-hardness (up to HV1800) of these particles thoughout the layer will guarantee a super wear resistant surface.
The overlay and base plate are metallurgical bonding. The overlay will penetrate into base plate about 0.8~1.8 mm, reaching up to 350 Mpa in our tests.
Packing:
Packaging: Steel pallet, Non fumigation pallets,Customized
Packaging Size: 1.4*3.4, 1.4*.3.0, customized.
Delivery Detail: Generally it is 5-10 days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according to quantity.
The Concrete Chute Hardfacing Wear Resistant Steel Plate we offer in stock is just some of our outstanding products, and we can also produce it according to your specifications. We want to be proactive, challenge each other, be well prepared for change and work tirelessly to achieve our goals. We make full use of the two international and domestic markets and two resources to enhance the platform service function.
