Wear Resistant Pipes are widely used in mines with serious wear, mineral fines and tailings transportation, coal-fired power plants for powder feeding, slag removal, ash conveying and other wear-resistant pipes are also very suitable.
The Wear Resistance of Ceramic-lined Composite Steel Pipe bends is more than 5 times higher than that of thick-walled wear-resistant cast steel bends. In practice, the ceramic-lined composite steel pipe is opened and observed and measured after 1-2 years, and the composite layer has no obvious wear or shedding.
In the same specification and unit length of the pipe, the ceramic-lined composite steel pipe only has the wear-resistant casting weight.
About 1/2 of the steel pipe or bimetallic composite pipe, the engineering cost per meter is reduced by 30-40%, only about 2/5 of the weight of the cast stone pipe and the rare earth wear-resistant steel pipe, and the engineering cost per meter is reduced by more than 20%.
Using the isostatic pressing production process, the high wear resistance of the ceramic tube is created!
Metallurgical and electric power industries consume a large amount of metal pipes every year to transport pulverized coal, ash, mud, lime gypsum slurry, etc. The use of ceramic composite pipes to replace other pipes has the characteristics of high wear resistance, long service life, convenient installation and significant economic benefits.
Ceramic wear-resistant elbows are used in coal-fired power plants for ash removal, slag discharge pipes, powder feeding, powder returning pipes, and desulfurization pipes, and are also widely used in the following industries:
Metal mines: Conveying wear-resistant elbows for concentrates and tailings;
Metallurgy: Blast furnace coal injection and slag conveying pipes for iron making in iron and steel plants; CAO, zinc and sand conveying pipes, ferroalloy conveying in steel making, out-of-furnace refining and other preferred wear-resistant elbows;
Cement plant: Raw slurry transportation, pulverized coal transportation, hoist unloading, finished cement pneumatic transportation loading and unloading of rotary kiln wet production line, concrete transportation wear-resistant elbow.
Chemical plant: Coal powder conveying pipeline, silicon powder and other raw material conveying wear-resistant elbows.
Mine: Mine filling, concentrate powder and tailings transportation have serious wear and tear on the pipeline. The service life of the ore powder transportation pipeline used in the past, such as Daye Mine, is less than one year. Changing to this pipe can increase the service life by about 5 times.
Coal: Coal preparation and long-distance pipeline coal transportation generally adopt wet transportation, which requires the transportation pipe to be both wear-resistant and corrosion-resistant.
1.Mosaic (wear-resistant pipe, elbow)
Ceramic composite wear-resistant pipe is to stick alumina ceramic sheet on the inner wall of the pipe with viscose.
This kind of product has a simple production process and a long service cycle. The use environment should not exceed 100 degrees.
2. Spot welding cassette (welded ceramic wear-resistant pipe, elbow)
Spot welding card type wear-resistant pipe is to stick the alumina ceramic sheet with holes in the middle to the inner wall of the pipe with high temperature resistant strong adhesive, and at the same time, with the spot welding process, the ceramic is firmly welded to the inner wall of the steel pipe through the small hole.
To protect the solder joints, a ceramic cap is screwed on top. The production process of this kind of product is relatively complicated, the wear resistance cycle is long.
3. Pipe bricks (wear-resistant pipes, elbows)
The special pipe bricks are pasted and spliced inside the elbow (pipe) to make it more firm. The pipe bricks can more effectively strengthen the firmness of ceramics and steel parts and enhance the service cycle.
1.Excellent wear resistance, continuous use for more than 10 years
2.Lining ceramics with high strength, high hardness and light weight
3.Smooth inner wall, no blocking powder
We are the manufacturer focus on wear resistant products with very rich experience for 13 years in China.
We are so lucky served so many mining companies,steel companies,power plants and cement plants at home and abroad.
Our products are exported to Russia, Pakistan, Brazil, Chile, India, Belgium,Turkey, Australia and other countries, and we continue to supply products to more countries and companies.Also gained good feedback.
We are not only provided products but also we have professional engineers and they can give some good suggestions.
Professional target market analysis , professional negotiating, professional service .
Professional wear-resistant solution with best offer , which our company persist on providing to our customer .
