1. Product Introduction
Alumina ceramic lining protection with high wear resistance and anti corrosion can prolong the useful life of the equipment. As the wear resistant is 200 times than steel plate and the hardness is much higher than steel.So alumina ceramic tiles have replaced so many steel products in mining, cement, power industry. All thickness and sizes are provided,from 3mm to 50mm.
Alumina ceramic include 92% alumina and 95% alumina with different shape.
Details
Product introduction: alumina ceramic lining, also known as: wear-resistant ceramic lining, high alumina lining, wear-resisting lining, lining of alumina, alumina ceramics, ceramic liner, microcrystal wear-resisting alumina lining
Application area: oil, mining, steel mills, power plants, cement industry such as conveying equipment or grinding resistance on the surface of the liquid flowing through a pipe material, main effect is effective against material passed by the effects of the shock tube wall, which can effectively extend the life cycle of equipment.
2.Product specifications
SHANDONG QISHUAI WEAR RESISTANT EQUIPMENT CO.,LTD | ||
PRODUCT CHEMICAL COMPOSITION AND PHYSICAL PROPERTIES | ||
Al2O3 | 92% | 95% |
SiO2 | 4.51% | 2.80% |
Fe2O3 | 0.01% | 0.01% |
TiO2 | 0.05% | / |
CaO | 1.8% | 0.45% |
MgO | 1.1% | 0.51% |
K2O | 0.04% | 0.03% |
Na2O | 0.31% | 0.63% |
Volume Density | 3.62 g/cm3 | 3.65 g/cm3 |
Water Absorption (%) | ≤0.02% | ≤0.02% |
POROSITY | ≤1 | ≤1 |
Hardness | 9 Mohs | 9 Mohs |
Flexural strength | ≥2000 Mpa | ≥2250 Mpa |
Abrasion | ≤0.02 | ≤0.02 |
Mainly products
wear resistant alumina tiles
alumina tiles for protection
Alumina Ceramic Lining
high temperature resistant ceramic tile
ceramic wear tiles
top grade alumina tile
pipe Lining Tile
Plain ceramic tiles
Weld ceramic tiles
Hex ceramic mat
Alumina ceramic mosaics
Actually,different field use different shape and thickness.We have near 10 years experience in wear resistant field,please let me know if u are not sure use whicj kind of shape and thickness.We will give u a professional suggestion.
3.Product Applications
